| Project | Contents |
|---|---|
| Model / Specifications | MHLDM-X(Where X denotes Airflow Capacity in m³/h) |
| Airflow Capacity | 1000–200000 m³/h |
| Dust inlet concentration | ≤2000mg/m³ |
| Efficiency | ≥98% |
| Applicable Exhaust Gas Types | Dust |
| Main Material | Carbon Steel / Stainless Steel |
| Control System | PLC Automated Pulse Jet Cleaning |
| Filtration Area | Tailored to Specific Models |
| Filter Bag Material | Polyester (PE), Acrylic, PPS, PTFE (Available in High-Temperature and Corrosion-Resistant grades) |
| Cleaning Pressure (Mpa) | 0.4–0.8MPa |
| Project | Contents |
|---|---|
| Functional Logic | Dust-laden gas enters the housing, where particulates are intercepted by filter bags and clean gas is discharged. The pulse valve automatically blows air to shake off dust into the hopper, ensuring continuous and stable dust removal. |
| Key Advantages | Extremely high filtration efficiency with low emission concentration Online/offline cleaning allows maintenance without downtime Long bag life and stable operating resistance Robust structure with excellent sealing Available high-temperature, corrosion-resistant & explosion-proof versions |
| Project | Contents |
|---|---|
| Treatment Capacity | Customizable equipment sizes based on specific flue gas volumes |
| Material Options | Optional anti-corrosive carbon steel/stainless steel housing |
| Explosion-proof Customization | Explosion-proof models available tailored to the properties of the dust-laden gas |
| High-Temperature Customization | Filter bags available in various materials to withstand specific flue gas temperatures |
| Anti-Corrosion Customization | Anti-corrosive filter bags available for handling corrosive dust-laden gases |
| Remote Monitoring | Optional remote monitoring system integration |
| Installation Method | Suitable for indoor/outdoor/steel frame installation |
| Project | Contents |
|---|---|
| Performance & Safety | · High Purification Efficiency: Ensures consistently stable emissions that fully comply with environmental standards |
| Operation & Maintenance | · Low OPEX & Energy Efficiency: Advanced energy-saving system design significantly reduces overall operational costs · Fully Automated Control: Smart PLC system enables unmanned operation, eliminating the need for dedicated on-site personnel |
| Customization & Durability | · Premium Durability: High-grade core materials ensure an extended service life coupled with simplified, hassle-free maintenance · Flexible Customization: Tailored airflow capacities and material configurations designed to perfectly match your specific site requirements |
